Aten PN5212 12-Port Power Over the NET

€539.95 €446.24
Discontinued
Power Distribution Unit (Strip 0-U high) 12 port (C13), 20 Ampere TCP/IP , Real Time measurement of total consumption

Description

ALTUSEN PN5212 Power Over the NET™ is a Power Distribution Unit that offers outlet level control combined with remote access to give IT administrators the ability to power control devices attached to the unit from practically any location via a TCP/IP connection. With support for power status measurement, PN5212 enables administrators to monitor the current, voltage and power consumption of their IT equipment at the PDU level, minimizing the power cost of running their equipment; and ensuring high levels of system availability for server rooms of all sizes.

The PN5212 PDU is highly suitable for server rooms or data centers with high-density server deployments. It features a space-saving 0U design that allows it to be mounted vertically on the outside of the rack, resulting in a more efficient use of server room space, and the elimination of the usual cable clutter.

A measuring feature, coupled with a threshold alarm, keeps you informed of the operating status of all your attached equipment. Warning messages regarding triggered alarms can be sent via an SMTP server. IT administrators are able to easily and conveniently monitor and power control connected devices – remotely if necessary – by means of a browser-based UI, thereby minimizing maintenance costs and ensuring 24/7 reliability for their server room operations.

The PN5212 can be daisy-chained to manage even more devices, so your server room management can expand in step with your company's growth. For ease of management, when PDUs are deployed in conjunction with other ALTUSEN products*, administrators can access them all from the same user interface. When a PDU is integrated in a CC (Control Center Over the NET™) management software installation, the power outlet of an IT device can be associated with its KVM port and displayed on the same CC web page. This allows IT administrators to completely control an IT device from a single user interface.
*KVM Over the NET™

Voor meer informatie.

Features


Power Distribution
Maximum Amps/Outlet: NEMA 20A / 12 outlets; IEC 16A / 12 outlets
Space saving 0U rack mount design
IEC or NEMA outlet models
Daisy chain up to 15 additional stations for up to 192 outlets
2 x 7 segment front panel LED shows Station and Outlet ID
Overcurrent protection and recovery for the PDU
Remote users can monitor outlet status via web pages on their browsers
Safe shutdown support
Separate power for the unit's own power and its power outlets. The user interface is still accessible even when an overload condition trips the devices' circuit breaker
Remote Access
Remote power control via TCP/IP and a built in 10/100 Mbps Ethernet port
Network Interfaces: TCP/IP, PPP, UDP, HTTP, HTTPS, SSL, SMTP, DHCP, ARP, NTP, DNS, Telnet, 10Base-T/100Base-TX, auto sense, Ping
IPv6 support
Operation
Local and Remote power outlet control (On, Off, Power Cycle) by individual outlets and outlet groups
Outlet group support at the PDU and Daisy-chain levels – the same action can be performed on a specified group of outlets at the same time
Supports redundant power management via daisy chaining and outlet groups
On/Off scheduling for individual outlets and outlet groups. Power management tasks can be scheduled on a daily, weekly, monthly, or user-specified times basis
Supports multiple power control methods – Wake on LAN, System After AC Back, Kill the Power
Power-on sequencing - users can set the power on sequence and delay time for each outlet to allow equipment to be turned on in the proper order
Easy setup and operation via a browser-based user interface
Multibrowser support (IE, Mozilla, Firefox, Safari, Opera, Netscape)
Telnet and SSH access for text menu configuration and outlet level switching / monitoring
Local console access support
Java GUI AP program provided for non-browser connectivity
RTC support to keep the timer running during times of no power
Up to 64 user accounts - up to 32 concurrent logins t
Management
Power status measurement at PDU level
LED indicators for current; voltage; power dissipation at the PDU level
Current; voltage; power dissipation; and energy consumption displayed in a browsed-based UI for monitoring at PDU and daisy-chain levels
Current, voltage, power dissipation, energy consumption threshold level setting
Alert threshold notification for selected events (On, Off, Recycle, Failure, etc.), via audio alarm and blinking LEDs (locally), SMTP, and SNMP trap notification
Naming support for outlets and outlet groups
User outlet access assignment on an outlet-by-outlet basis.
Windows-based Log Server; event logging, and syslog support
Integration with ALTUSEN CC2000 Management software and KVM devices
API for 3rd party software centralized control integration
Upgradeable firmware – daisy chained stations receive the upgrade via the daisy chain bus
Multi-language support: English, German, Traditional Chinese, Simplified Chinese, Japanese, Korean, Russian
Security
Three-level password security
IP/MAC filtering
Secure 128-bit SSL encryption
Remote authentication support: RADIUS, TACACS+, LDAP, LDAPS and Active Directory

Diagram

Content


3x Serial Adapters
• 1x SA0149 (RJ45F to DB9F)
• 1x SA0150 (RJ45F to DB9M)
• 1x SA0151 (RJ45F to DB9F)
2x Rack Mount Kits
1x Grounding Wire
1x User Manual
1x Quick Start Guide
1x Software CD

Specifications


Power Outlets Direct 12
Max. 192 (via Daisy Chain)
Connectors Power
Inlets
NEMA 1 x NEMA L5-20P
IEC 1 x IEC 60309
Power
Outlets
NEMA 12 x NEMA 5-15R
IEC 12 x IEC320 C13
PON In / Console 1 x RJ-45 (Female )
PON Out 1 x RJ-45 (Female )
LAN 1 x RJ-45 (Female )
LEDs ID 1 x 2-digit 7-segment
Station 1 (Green)
Readout 1 x 3-digit 7-segment
Current 1 (Green)
Voltage 1 (Green)
Power 1 (Green)
I/P Rating
(Total Input)
NEMA 100-120V; 50/60Hz; 16A
IEC 200-240V; 50/60Hz; 16A
Load Capacity NEMA 120V; 50/60Hz; 1920W
IEC 230V; 50/60Hz; 3680W
O/P Rating Per Port NEMA 100-120V; 50/60Hz; 12A
IEC 200-240V; 50/60Hz; 10A
Total NEMA 100-120V; 50/60Hz; 15A
IEC 200-240V; 50/60Hz; 15A
Power Consumption NEMA 120V; 50/60Hz; 16W
IEC 230V; 50/60Hz; 18W
Environment Operating Temp. 0 - 50°C
Storage Temp. -20 - 60°C
Humidity 0-80% RH Non-condensing
Physical Properties Housing Metal
Weight 4.49 kg
Dimensions
( L x W x H )
6.42 x 5.46 x 134 cm
* The specification and pictures are subject to change without notice.
* All trademarks and logos are the properties of their respective holders.
