| Function | VE150AT | VE150AR | ||
| Display Connections | 1 | 1 | ||
| Connectors | Input | Video | 1 x HDB-15 Male (Blue) | N/A |
| Output | Video | 1 x HDB-15 Female (Blue) | 1 x HDB-15 Female (Blue) | |
| Unit to Unit | 1 x RJ-45 Female (Black) | 1 x RJ-45 Female (Black) | ||
| Power | 1 x DC Jack | 1 x DC Jack | ||
| Switches | Manual Gain Control | N/A | 1 x Knob | |
| LEDs | Power | 1 (Green) | 1 (Green) | |
| Video | 1920x1200 @ 60Hz (30 m); 1600x1200 @ 60Hz (100 m); 1280x1024 @ 60Hz (150 m) | |||
| Power Consumption | DC5.3V, 1.0W | DC5.3V, 1.2W | ||
| Environment | Operating Temp. | 0 - 50°C | ||
| Storage Temp. | -20 - 60°C | |||
| Humidity | 0 - 80% RH, Non-condensing | |||
| Physical Properties | Housing | Metal | ||
| Weight | 0.24 kg | |||
| Dimensions (L x W x H) |
12.77 x 9.04 x 2.26 cm | |||
