| Function | VE809T | VE809R | ||
| Connectors | Device | HDMI IN | 2 x HDMI type A Female (Black) | N/A |
| Display | HDMI OUT | 1 x HDMI type A Female (Black)(Loop-through) | 1 x HDMI type A Female (Black) | |
| IR | 1 x IR receiver (Black) | 1 x IR receiver (Black) | ||
| Power | 1 x DC jack | 1 x DC jack (Mini USB) | ||
| Unit to Unit | Wireless 5Ghz | Wireless 5Ghz | ||
| Switches | Power | 1 x Pushbutton | 1 x Pushbutton | |
| Switch | 1 x Pushbutton | 1 x Pushbutton | ||
| LEDs | Power | 1 (Blue/Red) | 1 (Blue/Red) | |
| Port ID | 2 (Blue) | 2 (Blue) | ||
| Video | 480p, 720p, 1080i and 1080p | |||
| Audio | Up to 5.1 channel digital audio | |||
| Transmission Distance | Up to 30 m | |||
| Power Consumption | DC5V, 10W | DC5V, 7.5W | ||
| Environment | Operating Temp. | 0–40°C | ||
| Storage Temp. | -20–60°C | |||
| Humidity | 0–80% RH, Non-condensing | |||
| Physical Properties |
Housing | Plastic | ||
| Weight | 205 g | 125 g | ||
| Dimensions (L x W x H) |
18.20x 9.65 x 3.15 cm | 9.50 x 9.50 x 3.15 cm | ||
