| Connectors | DVI Out | 4 x DVI-D Female (White) |
| Audio Out * | 4 x captive screw connector, 5 pole | |
| Power Consumption | DC5V, 20.10W | |
| Environment | Operating Temp. | 0–40°C |
| Storage Temp. | -20–60°C | |
| Humidity | 0–80% RH, Non-condensing | |
| Physical Properties |
Housing | Metal |
| Weight | 0.58 kg | |
| Dimensions (L x W x H) |
35.20 x 23.80 x 2.28 cm | |
Note:
* Audio signal type support stereo, balanced/unbalanced.
Balanced audio maximum input/output level: 0.5 Vrms (-6.02dBV@600 ohm)
Unbalanced audio maximum input/output level: 1Vrms (0dBV@600ohm)
The specification and pictures are subject to change without notice.
* All trademarks and logos are the properties of their respective holders.
