Aten AS251S RS232 Serial Auto Switch (2 to 1)

€ 34,45 € 28,47
Direct leverbaar
Input: 2(DEC) DB-25 Female, Output : 1(DEC) DB-25 Male

Omschrijving


AS251S allows 2 PCs to share 1 serial (RS232) printer. It is easy to install and needs no additional power supply.
Voor meer informatie.

Features


• No External Power required.
• Output Port Selectable.
• Tran sparent to the user.
• OS Compatibility: WIN98, WIN ME, WIN 2K and WIN XP.

inhoud


• 1x Serial Auto Switch
• 1x User Manual

Specifications



Connectors Input (DCE) 2 x RS-232 DB-25 Female
Output (DTE) 1 x RS-232 DB-25 Male
LEDs Input 2
Port Selection Input Auto / Manual
Input Arbitration First come first served
Function Key Manual / Select
Timeout Selection 10 ~ 60 seconds
Power Consumption AC 9V 100mA (max.)
Cable Length 15 m [50'] (max.)
Environment Operating Temperature 0 ~50?C
Storage Temperature -20 ~ 60?C
Humidity 0~80% RH, NC
Physical Properties Housing Plastic
Weight 0.13 kg
Dimension( L x W x H ) 10.2 x 8.5 x 2.6 cm

* The specification and pictures are subject to change without notice.
* All trademarks and logos are the properties of their respective holders.
