| Computer Connections | 2 |
| Port Selection | Pushbutton |
| Connectors | |
| Console Ports | 2 x USB Type A Female (Black) 1 x HDB-15 Female (Blue) 1 x mini stereo Jack Female (Pink) 1 x mini stereo Jack Female (Green) |
| KVM Ports | 2 x SPHD-18 Female (Green) |
| Power | 1 x DC 5V Jack (Spare) |
| LEDs | |
| Online | 2 (Orange) |
| Selected | 2 (Green) |
| Switches | |
| Selected | 2 x Pushbuttons |
| Video | 2048 x 1536 @ 60 Hz; DDC2B |
| Power Consumption | DC5V:0.142W:5BTU |
| Environmental | |
| Operating Temperature | 0-50°C |
| Storage Temperature | -20-60°C |
| Humidity | 0 - 80% RH, Non-condensing |
| Physical Properties | |
| Housing | Metal |
| Weight | 0.45 kg ( 0.99 lb ) |
| Dimensions (L x W x H) | 13.00 x 7.65 x 4.40 cm (5.12 x 3.01 x 1.73 in.) |
| Note | For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format. |
