ATEN PE0110SG Standaard 1U PDU met overspanningsbeveiliging

€ 56,80 € 46,94
Levertijd: 3-5 werkdagen
Standaard 1U PDU met overspanningsbeveiliging

Omschrijving

De PE0110S van Aten is een stroomverdeeleenheid (PDU) met 10 stopcontacten en voor 1U rekmontage die IEC- en NEMA-output levert. Het verdeelt de stroom naar 10 stopcontacten vanuit een enkele stekker met ongefilterde elektrische doorvoer. De PE0110S biedt ook overspanningsbeveiliging en voorkomt schade aan uw apparatuur door overspanning en stroompieken. De geïntegreerde overspanningsbeveiliging is voorzien van een led-indicator, die de status van uw apparatuur aangeeft.

Eigenschappen

  • Ruimtebesparend - ontwerp voor 1U rekmontage
  • Modellen met IEC- of NEMA-stopcontact
  • Overspanningsbeveiliging
  • Overstroombeveiliging
  • Aluminium materiaal
  • Werkt met datacenters, serverruimten en telecomapparatuur

Diagram

inhoud

1x PE0110S standaard PDU
1x LINP-10F3-2B0G voedingskabel
1x gebruikersinstructies

Specifications

FunctionPE0110SAPE0110SG
Electrical
Nominal Input Voltage100-120 VAC100-240 VAC
Maximum Input Current15A (Max)
(UL de-rated 12A Max)
10A (Max)
Input Frequency50-60 Hz50-60 Hz
Input ConnectionNEMA 5-15PFor G Plug:IEC-320 C14
For Z Plug:Chinese 10A
Input Power1800VA(Max);1440VA(UL de-rated)2400VA(Max)
Outlet Type(10) NEMA 5-15R(10) IEC-320 C13
Maximum Output Current (Outlet)15A (Max)
(UL de-rated 12A Max)
10A (Max)
Maximum Output Current (Bank)15A (Max)
(UL de-rated 12A Max)
10A (Max)
Maximum Output Current (Total)15A (Max)
(UL de-rated 12A Max)
10A (Max)
OPD(Overcurrent Protection Device)YESYES
Physical Properties
Dimensions (L x W x H)48.20 x 4.44 x 4.50 cm
(18.98 x 1.75 x 1.77 in.)
48.20 x 4.44 x 4.50 cm
(18.98 x 1.75 x 1.77 in.)
Weight0.66 kg ( 1.45 lb )0.66 kg ( 1.45 lb )
Power Cord Length10ft(14#)10ft(3×1.5mm2)
Environmental
Temperature (Operating / Storage)0 – 40℃ / -20 – 60℃
*When the environmental temperature comes close 40 degrees, it is recommended to lower the load to 60% to comply to the safety regulations.
0 – 40℃ / -20 – 60℃
*When the environmental temperature comes close 40 degrees, it is recommended to lower the load to 60% to comply to the safety regulations.
Elevation (Operating / Storage)3000m3000m
Compliance
EMC VerificationFCC Class A-
Safety VerificationBy RequestCE,LVD
