| Function | VE883AR | VE883AT |
| Video Input |
| Interfaces | N/A | 1 x HDMI Type A Female (Black) |
| Impedance | N/A | 100 Ω |
| Max. Distance | N/A | Up to 5 m |
| Video Output |
| Interfaces | 1 x HDMI Type A Female (Black) | N/A |
| Impedance | 100 Ω | N/A |
| Max. Distance | Up to 5 m | N/A |
| Video |
| Max. Data Rate | 10.2 Gbps (3.4 Gbps Per Lane) | 10.2 Gbps (3.4 Gbps Per Lane) |
| Max. Pixel Clock | 594 MHz | 594 MHz |
| Compliance | HDMI (3D, Deep Color, 4K)
HDCP 2.2/2.3 Compatible | HDMI (3D, Deep Color, 4K)
HDCP 2.2/2.3 Compatible |
| Max. Resolution | 4096x2160@60Hz (4:4:4) / 3840x2160@60Hz (4:4:4) | 4096x2160@60Hz (4:4:4) / 3840x2160@60Hz (4:4:4) |
| Max. Distance | 1 x SFP Module (*Note)
VE883AK1: 4Kx2K/60Hz 4:4:4 up to 300m (MM, OM3, Black)
VE883AK2: 4Kx2K/60Hz 4:4:4 up to 10km (SM, Blue) | 1 x SFP Module (*Note)
VE883AK1: 4Kx2K/60Hz 4:4:4 up to 300m (MM, OM3, Black)
VE883AK2: 4Kx2K/60Hz 4:4:4 up to 10km (SM, Blue) |
| Audio |
| Input | N/A | 1 x Terminal Block, 5 pole (Green) |
| Output | 1 x Terminal Block, 5 pole (Green) | N/A |
| Connectors |
| Unit To Unit | 1 x bi-directional SFP (LC) | 1 x bi-directional SFP (LC) |
| Firmware Upgrade | 1 x Micro USB (Type B) Female (Black) | 1 x Micro USB (Type B) Female (Black) |
| Power | 1 x DC Jack with locking | 1 x DC Jack with locking |
| Fiber Optics |
| Data Rate | 10.3 Gbps | 10.3 Gbps |
| Wavelength | VE883AK1: 850 nm
VE883AK2: 1310 nm | VE883AK1: 850 nm
VE883AK2: 1310 nm |
| Fiber Type | VE883AK1: Multimode(MM), OM3, LC Duplex Type
VE883AK2: Singlemode(SM), LC Duplex Type | VE883AK1: Multimode(MM), OM3, LC Duplex Type
VE883AK2: Singlemode(SM), LC Duplex Type |
| Control |
| USB Channel | 2 x USB Type A Female (White) | 1 x USB Type B Female (White) |
| RS-232 Channel | 1 x Terminal Block, 3 pole (Green) | 1 x Terminal Block, 3 pole (Green) |
| IR Channel | 1 x Mini Stereo Jack Female (Black);
30K~56 KHz full range transmission | 1 x Mini Stereo Jack Female (Black);
30K~56 KHz full range transmission |
| Ethernet Channel | 1 x GbE (RJ-45 Female) | 1 x GbE (RJ-45 Female) |
| LEDs |
| Power | 1 (Green) | 1 (Green) |
| Link | 1 (Orange) | 1 (Orange) |
| Video Output | 1 (Orange) | N/A |
| Power Consumption | DC12V:6.5W:52BTU/h | DC12V:5.57W:26BTU/h |
| Environmental |
| Operating Temperature | 0-40°C | 0-40°C |
| Storage Temperature | -20 - 60°C | -20 - 60°C |
| Humidity | 0 - 80% RH, Non-Condensing | 0 - 80% RH, Non-Condensing |
| Physical Properties |
| Housing | Metal | Metal |
| Weight | 0.66 kg ( 1.45 lb ) | 0.67 kg ( 1.48 lb ) |
| Dimensions (L x W x H) with bracket | 16.94 x 14.69 x 3.00 cm
(6.67 x 5.78 x 1.18 in.) | 16.94 x 14.69 x 3.00 cm
(6.67 x 5.78 x 1.18 in.) |
| Dimensions (L x W x H) without bracket | 16.60 x 12.49 x 2.90 cm
(6.54 x 4.92 x 1.14 in.) | 16.60 x 12.49 x 2.90 cm
(6.54 x 4.92 x 1.14 in.) |
| Note | 1. Operating distance is approximate. A typical maximum distance may vary depending on factors such as fiber type, bandwidth, connector splicing, losses, modal or chromatic dispersion, environmental factors, and kinks.
2. It is recommended that you use Single Mode fibers that conforms to IEC 60793- 2-50 B1.1 or ITU-T G.652.B specifications; Use Multi Mode fibers that conform to IEC 11801 (OM3) specifications.
3. The Device is class 1 laser product. It meet the safety regulations of IEC-60825, FDA 21 CFR 1040.10, and FDA 21 CFR 1040.11. | 1. Operating distance is approximate. A typical maximum distance may vary depending on factors such as fiber type, bandwidth, connector splicing, losses, modal or chromatic dispersion, environmental factors, and kinks.
2. It is recommended that you use Single Mode fibers that conforms to IEC 60793- 2-50 B1.1 or ITU-T G.652.B specifications; Use Multi Mode fibers that conform to IEC 11801 (OM3) specifications.
3. The Device is class 1 laser product. It meet the safety regulations of IEC-60825, FDA 21 CFR 1040.10, and FDA 21 CFR 1040.11. |
