| Video Input | |
| Interface | 8 x DVI-D Female (White) |
| Impedance | 100 ? |
| Max. Distance | 1.8 m |
| Video Output | |
| Interface | 8 x DVI-D Female (White) |
| Impedance | 100 ? |
| Video | |
| Max. Data Rate | 6.75 Gbps (2.25 Gbps Per Lane) |
| Max. Pixel Clock | 225 MHz |
| Compliance | HDCP 1.4 Compatible |
| Max. Resolution | Up to 1920 x 1200 |
| Max. Distance | Up to 5m |
| Control | |
| RS-232 | Connector: 1 x DB-9 Female (Black) Baud Rate and Protocol: Baud Rate: 19200, Data Bits: 8, Stop Bit: 1, Parity: No, Flow Control: No |
| IR | 1 x Mini Stereo Jack Female (Black) |
| Ethernet | 1 x RJ-45 Female (Black) |
| EDID Settings | EDID Mode: Default / Port 1/ Remix / Customized |
| Power | |
| Connectors | 1 x 3-Prong AC Socket |
| I/P Rating | 100-240VAC; 50-60Hz; 1.0A |
| Consumption | 120VAC, 56.4W; 230VAC, 55.9W |
| Environmental | |
| Operating Temperature | 0-50°C |
| Storage Temperature | -20 - 60°C |
| Humidity | 0 - 80% RH, Non-Condensing |
| Physical Properties | |
| Housing | Metal |
| Weight | 4.25 kg |
| Dimensions (L x W x H) | 43.24 x 25.98 x 4.4 cm |
